Old 10 October 2009   #1
Smoke Bomb

hello,ppl can u tell me how can i catch soft smoke bomb fx using maya fluid.
if anybody has try this b4 then plz share ur experience.Thank you

Smoke Bomb Detail 1
Smoke Bomb Detail 2
Smoke Bomb Detail 3

Old 10 October 2009   #2
very high res, very low diffusion on density, use boyancy to drive the smoke, heat driven turbulence, lots of swirl. color shading would be pretty flat, use self shadowing.

id use a 2d fluid because you need very high res. in general you should setup the effect in a high res 2d fluid and then go from there.

p.s. to get the kind of wispy as what you see on the far right, that looks like it would require a texture on the opacity. but id keep textures away from the emitter source. a distance gradient on texture would work.
__________________
From Russia, with love @ stooch.tv

Last edited by stooch : 10 October 2009 at 07:54 PM.

Old 10 October 2009   #3
for this kind of effect particle clouds simulation shaded with a fluid shader , is also very interesting. a black and white puffy clouds fluids shader with an RGB lighting in xyz + self shadowing for your render pass. then you color your smoke and give volume to your clouds with your favorites compositing soft .

if swirl is very important you can use particles modify by a fluids ...
__________________
emfx.fr

Last edited by SebKaine : 10 October 2009 at 09:47 PM.

Old 10 October 2009   #4
Hey,stooch & SebKaine thnx 4 reply.And now i want to make choice with only maya fluids.And want to learn more from this post:Driving Fluid Attributes (Buoyancy,Swirl,etc) with Textures


Old 10 October 2009   #5
Killer Box

Hello,i want to make "Killer Box" i mean when fluids enter to perticular area it will destroy.Same funda like lifespanPP=0
if u know some expression or elzzz plz tell me fast.

Old 10 October 2009   #6
Make a volume fluid emitter set at -1000 density. that should "kill" it
__________________
pauljewell.com

Old 10 October 2009   #7
Maybe something along these lines?


I'm going to try to render the full animation tonight and if it's good ruchitinfushion, I'll share the scene file.

Edit: the scene file and the video.

-shawn
__________________
twitter | vimeo

Last edited by YourDaftPunk : 10 October 2009 at 02:45 AM.

Old 10 October 2009   #8
Thumbs up

hy shawn,

would really appreciate if you shared the scenefile !

Old 10 October 2009   #9
Animation turned out ok.

It's up on vimeo:
http://www.vimeo.com/7278627

And the scene is here:
http://shawnlipowski.com/forumFiles...fluids_demo.zip

That render had an nCache with samples set to 0.5 and I saved every 2 samples (making it cache of 24 fps, but a simulation of 48 fps). I cached density and texture, but the texture movement comes more from a translation of the texture origin (see the expression in the scene).

Second, it's over 5 million voxels (3 hours to cache), so try testing it with a res of 50x110x220 which is only 1.38 million voxels. You also don't have to sample at 48fps when testing.

-shawn
__________________
twitter | vimeo

Old 10 October 2009   #10
Thumbs up Time To Celebrate festival

OMG......Wonderfull job.Hello PPL try to use this bomb in Christmas and spread the color of love.Thank you YourDaftPunk

Old 10 October 2009   #11
nice work Shawn ... thanks for sharing
__________________
LDEA Kon Kuatica

Old 10 October 2009   #12
